Products & Applications

Hardcoat Films

The durability and optical qualities of polyester (PET) and polycarbonate (PC) films serves as an excellent foundation for the high precision roll-to- roll (R2R) coating application of Kimoto’s chemically bonded UV hardcoat surface treatments.

A proprietary nano-structured coating provides functional, aesthetic, mechanical and haptic properties while our custom engineered coating lines process the material under an ISO accredited quality system.

Features, Advantages and Benefits

  • Flexiber PET films offer UV light blocking/light filtering properties
  • Flexiber PC film offers a UL94-VO flame rating
  • ElastoDur PET films offer dimensional stability and a “universal” print primer
  • KB-FILMS offer high light transmission, low haze, optical grade surface cosmetics
  • All films offer a durable surface that resists scratching, marring and scuffing
  • Advanced coating process ensures batch to batch consistency

Enhanced Functionality

In addition to our standard products we offer some advanced options including:

  • Anti-Newton ring coatings to improve optical properties and replace the step of using spacers
  • Oleophobic/Anti-fingerprint coatings to render fingerprints imperceptible as the oil is dispersed across the surface and allows light to pass through
  • Coatings to block UV light, UV transmission @380nm is 2% +/-1%

ElastoDur and Flexiber Applications

  • Membrane Switch
  • Graphic Overlays
  • Touch Screens
  • Touch Sensors
  • Wearable Sensors
  • Displays
  • Fascia Panels
  • Nameplates
  • Flexible Printed Electronics

For further information, please visit our dedicated ElastoDur product page.

KB-FILM Applications

  • ITO sputtering base
  • Conductive printing base
  • Metallizing base

Product Range

  • Surface finishes: gloss, anti-glare, texture, planarized
  • Film Thickness: 2 mil (50 micron), 5 mil (130 micron), 7.5 mil (188 micron), 10 mil (250 micron)
  • Protective masking - supplied on the print treat side for protection and to eliminate "blocking"
